| Onderdeel nommer | TM101DDHG05 |
| Handelsmerk | TIANMA |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | TIANMA |
| diagonale grootte | 10.1 inch |
| pixel formaat | 1024(RGB)×600 [WSVGA] 117PPI |
| aktiewe area | 222.72(H)×125.28(V) mm |
| ring area | - |
| helderheid | 1400 cd/m² (Typ.) |
| kyk rigting | 12 o'clock |
| kykhoek | 80/80/75/80 (Typ.)(CR≥10) |
| ondersteun kleur | 262K/16.7M 47% NTSC |
| gewig | - |
| raamkoers | 60Hz |
| model | TM101DDHG05 |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 235(H)×143(V) ×7.8(D) mm |
| behandeling | Antiglare, Hard coating |
| kontras verhouding | 500:1 (Typ.) (TM) |
| reaksie tyd | 7/9 (Typ.)(Tr/Td) |
| bedryfsmodus | TN, Normally White, Transmissive |
| Ligbron | WLED [14S3P] , 30K hours , W/O Driver |
| ontwerp vir | Industrial |
| raakpaneel | Without |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| BT101IW02 V.0 | Innolux | 10.1 | 1024×600 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| HSD101PFW2-C00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
