| Onderdeel nommer | TM101DDHG04 |
| Handelsmerk | TIANMA |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 262K/16.7M |
| Agterlig | 10S3P |
| Koppelvlak | |
| paneel handelsmerk | TIANMA |
| paneel grootte | 10.1" |
| resolusie | 1024(RGB)×600, WSVGA, 117PPI |
| vertoon area | 222.72(W)×125.28(H) mm |
| omtrek grootte | 233.1(W)×137.1(H) ×3.3(D) mm |
| helderheid | 300 cd/m² (Typ.) |
| kykhoek | 80/80/75/80 (Typ.)(CR≥10) |
| beste uitsig op | 12 o'clock |
| kleure vertoon | 262K/16.7M 47% NTSC |
| frekwensie | 60Hz |
| gewig | 210/220g (Typ./Max.) |
| paneel model | TM101DDHG04 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 225.72(W)×128.28(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 7/9 (Typ.)(Tr/Td) |
| tipe lamp | 10S3P WLED , 15K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial |
