| Onderdeel nommer | TM097TDHG04-02 |
| Handelsmerk | TIANMA |
| Grootte | 9.7 |
| Toepassing | Pad & Tablet Industr |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | 6S6P |
| Koppelvlak | LVDS |
| paneel handelsmerk | TIANMA |
| paneel grootte | 9.7" |
| resolusie | 1024(RGB)×768, XGA, 132PPI |
| vertoon area | 196.608(W)×147.456(H) mm |
| omtrek grootte | 210.2(W)×166.3(H) ×5.85(D) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 70/70/60/70 (Typ.)(CR≥10) |
| beste uitsig op | 12 o'clock |
| kleure vertoon | 262K 50% NTSC |
| frekwensie | 60Hz |
| paneel gewig | 200g (Typ.) |
| sein koppelvlak | LVDS (1 ch, 6-bit) , 30 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| paneel model | TM097TDHG04-02 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 200.91(W)×152.27(H) mm |
| oppervlak | Clear |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 20/25 (Typ./Max.)(Tr+Td) |
| tipe lamp | 6S6P WLED , 30K hours , Without Driver |
| raakskerm | Without |
| aansoek | Pad & Tablet Industrial |
