| Onderdeel nommer | TM080VDSP03 |
| Handelsmerk | TIANMA |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | 7S3P |
| Koppelvlak | |
| paneel handelsmerk | TIANMA |
| paneel grootte | 8.0" |
| resolusie | 1200(RGB)×1920, WUXGA, 283PPI |
| vertoon area | 107.64(W)×172.224(H) mm |
| omtrek grootte | 114.58(W)×184.09(H) ×3.95(D) mm |
| helderheid | 390 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 60% NTSC |
| frekwensie | 60Hz |
| paneel gewig | TBD |
| insetspanning | 3.3V (Typ.)(VCI) |
| omgewing | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -15 ~ 70 °C |
| paneel model | TM080VDSP03 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Hard coating |
| kontras verhouding | 800:1 (Typ.) (TM) |
| vertoonmodus | SFT, Normally Black, Transmissive |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| tipe lamp | 7S3P WLED |
| raakskerm | Without |
| aansoek | Pad & Tablet |
