| Onderdeel nommer | TM080RBHG30 |
| Handelsmerk | TIANMA |
| Grootte | 8.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K/16.7M |
| Agterlig | 3S12P |
| Koppelvlak | |
| vervaardiger | TIANMA |
| model naam | TM080RBHG30 |
| skerm grootte | 8.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 800(RGB)×480 (WVGA) 116PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 176.64 × 99.36 (H×V) |
| buitelyn (mm) | 192.8 × 116.9 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 375 cd/m² (Typ.) |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| kykhoek | 70/70/60/70 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | - |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 262K/16.7M 65% NTSC |
| agterlig | 3S12P WLED , 20K hours , No Driver |
| massa | 280g (Typ.) |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AT080TN42 V.1 | Innolux | 8.0 | 800×600 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| LD080UX1-SMA2 | LG Display | 8.0 | 1200×1600 |
| TM080SDH01 | Tianma | 8.0 | 800×600 |
| TM080SV-04L01 | SANYO | 8.0 | 800×600 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
| TM080XPH01 | Tianma | 8.0 | 1280×768 |
