| Onderdeel nommer | TM070RDHG34 |
| Handelsmerk | TIANMA |
| Grootte | 7.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 800×480 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | 3S8P |
| Koppelvlak | |
| vervaardiger | TIANMA |
| model naam | TM070RDHG34 |
| skerm grootte | 7.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 800(RGB)×480 (WVGA) 134PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 154.08 × 85.92 (H×V) |
| buitelyn (mm) | 164.9 × 100 × 6 (H×V×D) |
| ring area (mm) | 157.08 × 89.39 (H×V) |
| behandeling | Antiglare |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| kykhoek | 70/70/60/70 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | 6 o'clock |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 16.7M 50% NTSC |
| agterlig | 3S8P WLED , 50K hours , No Driver |
| massa | TBD |
| gebruik vir | Industrial Outdoor High Brightness Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
