| Onderdeel nommer | TM070RDHG25 |
| Handelsmerk | TIANMA |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K |
| Agterlig | 3S8P |
| Koppelvlak | |
| paneel handelsmerk | TIANMA |
| paneel grootte | 7.0" |
| resolusie | 800(RGB)×480, WVGA, 134PPI |
| vertoon area | 154.08(W)×85.92(H) mm |
| omtrek grootte | 164.9(W)×100(H) ×8.1(D) mm |
| helderheid | 450 cd/m² (Typ.) |
| kykhoek | 80/80/60/80 (Typ.)(CR≥10) |
| beste uitsig op | 6 o'clock |
| kleure vertoon | 262K 50% NTSC |
| frekwensie | 60Hz |
| gewig | TBD |
| paneel model | TM070RDHG25 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 157.08(W)×89.39(H) mm |
| oppervlak | Antiglare |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 15 (Typ.)(Tr+Td) |
| tipe lamp | 3S8P WLED , 20K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial |
