| Onderdeel nommer | TM070DVHG01-41 |
| Handelsmerk | TIANMA |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 16.7M |
| Agterlig | 3S6P |
| Koppelvlak | |
| paneel handelsmerk | TIANMA |
| paneel grootte | 7.0" |
| resolusie | 1024(RGB)×600, WSVGA, 169PPI |
| vertoon area | 153.6(W)×90(H) mm |
| omtrek grootte | 171.5(W)×110.3(H) ×5.3(D) mm |
| helderheid | 270 cd/m² (Typ.) |
| kykhoek | 75/75/70/75 (Typ.)(CR≥10) |
| beste uitsig op | 12 o'clock |
| kleure vertoon | 16.7M 50% NTSC |
| frekwensie | 60Hz |
| gewig | - |
| paneel model | TM070DVHG01-41 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | - |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 20 (Typ.)(Tr+Td) |
| tipe lamp | 3S6P WLED , 20K hours , Without Driver |
| raakskerm | PCAP |
| aansoek | Industrial |
