| Onderdeel nommer | TM062RDZG10 |
| Handelsmerk | Tianma |
| Grootte | 6.2 |
| Toepassing | CNS |
| Resolusie | 800×480 |
| Samestelling | LCM |
| Helderheid | |
| CR | |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | TIANMA |
| paneel model | TM062RDZG10 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 6.2 inch |
| resolusie | 800(RGB)×480 , WVGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 137.4×77.28 mm |
| oppervlak | |
| helderheid | |
| kontras verhouding | |
| kleure vertoon | 16.7M (8-bit), CIE193150% |
| reaksie tyd | |
| kykhoek | 75/65/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDWithout Driver |
| aansoek | CNS |
| AT062TN12 | Innolux | 6.2 | |
| AT070TN84 V.1 | Innolux | 7.0 | 800×480 |
| C070VW04 VB | AUO | 7.0 | 800×480 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| CLAA070LFB1 CW | CPT | 7.0 | 800×480 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LQ058T5DG02F | SHARP | 5.8 | 480×240 |
| LQ070T5DR06 | SHARP | 7.0 | 480×240 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| PW062XU7 | E Ink | 6.2 | 480×234 |
