| Onderdeel nommer | TM060RDH03 |
| Handelsmerk | Tianma |
| Grootte | 6.0 |
| Toepassing | DPF |
| Resolusie | 800×480 |
| Samestelling | LCM |
| Helderheid | 350 |
| CR | 500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | TTL |
| paneel handelsmerk | TIANMA |
| paneel model | TM060RDH03 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 6.0 inch |
| resolusie | 800(RGB)×480 , WVGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 133.2×73.8 mm |
| buitelyn | 145.5×87.8 mm |
| oppervlak | Antiglare |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 500:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE193150% |
| reaksie tyd | 20/30 (Typ./Max.)(Tr+Td) |
| kykhoek | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 7S3PWLEDWithout Driver |
| sein koppelvlak | Parallel RGB (1 ch, 8-bit), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | DPF |
