| Onderdeel nommer | TM050RDZG03-30 |
| Handelsmerk | TIANMA |
| Grootte | 5.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 600:1 |
| Kleure | 16.7M |
| Agterlig | 3S6P |
| Koppelvlak | |
| vervaardiger | TIANMA |
| model naam | TM050RDZG03-30 |
| skerm grootte | 5.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 800(RGB)×480 (WVGA) 188PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 108 × 64.8 (H×V) |
| buitelyn (mm) | 120.7 × 77.8 × 5.9 (H×V×D) |
| ring area (mm) | 111.1 × 67.9 (H×V) |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 600 : 1 (Typ.) (TM) |
| kykhoek | 70/70/50/70 (Typ.)(CR≥10) |
| reaksie | 20/30 (Typ./Max.)(Tr+Td) ms |
| goeie uitsig by | 12 o'clock |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 16.7M 50% NTSC |
| agterlig | 3S6P WLED , 50K hours |
| massa | TBD |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
