| Onderdeel nommer | TM050RDH13 |
| Handelsmerk | TIANMA |
| Grootte | 5.0 |
| Toepassing | Automotive Display |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | TIANMA |
| paneel grootte | 5.0" |
| resolusie | 800(RGB)×480, WVGA, 188PPI |
| vertoon area | 108(W)×64.8(H) mm |
| helderheid | - |
| kykhoek | - |
| beste uitsig op | - |
| kleure vertoon | 16.7M 50% NTSC |
| frekwensie | 60Hz |
| gewig | - |
| paneel model | TM050RDH13 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 20 (Typ.)(Tr+Td) |
| tipe lamp | WLED |
| raakskerm | Without |
| aansoek | Automotive Display |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| TM050JVZG28 | Tianma | 5.0 | 720×1280 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
| TM050QDH01 | Tianma | 5.0 | 640×480 |
| TM050QDH06 | Tianma | 5.0 | 640×480 |
| TM050QDH07 | Tianma | 5.0 | 640×480 |
| TM050QDH11 | Tianma | 5.0 | 640×480 |
| TM050RBH01 | Tianma | 5.0 | 800×480 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
