| Onderdeel nommer | TM035HDZP04 |
| Handelsmerk | TIANMA |
| Grootte | 3.5 |
| Toepassing | Automotive Display |
| Resolusie | 240×320 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | TIANMA |
| paneel grootte | 3.5" |
| resolusie | 240(RGB)×320, QVGA, 114PPI |
| vertoon area | 53.28(W)×71.04(H) mm |
| helderheid | - |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 262K |
| frekwensie | 60Hz |
| gewig | - |
| paneel model | TM035HDZP04 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 58.28(W)×74.04(H) mm |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | SFT, Normally Black, Transmissive |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| tipe lamp | WLED , 10K hours , Without Driver |
| raakskerm | - |
| aansoek | Automotive Display |
