| Onderdeel nommer | TM028HDZG59 |
| Handelsmerk | TIANMA |
| Grootte | 2.8 |
| Toepassing | Mobile Phone |
| Resolusie | 240×320 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 400:1 |
| Kleure | 65K/262K |
| Agterlig | WLED |
| Koppelvlak | 16-bit |
| handelsmerk | TIANMA |
| diagonale grootte | 2.8 inch |
| pixel formaat | 240(RGB)×320 [QVGA] 141PPI |
| aktiewe area | 43.2(H)×57.6(V) mm |
| helderheid | 300 cd/m² (Typ.) |
| kyk rigting | - |
| kykhoek | 70/70/70/58 (Typ.)(CR≥10) |
| ondersteun kleur | 65K/262K 63% NTSC |
| gewig | TBD |
| raamkoers | - |
| koppelvlak tipe | 16-bit 8080 parallel , 37 pins FPC |
| kragtoevoer | 2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | TM028HDZG59 |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 50(H)×69.2(V) mm |
| kontras verhouding | 400:1 (Typ.) (TM) |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| bedryfsmodus | TN, Normally White, Transmissive |
| Ligbron | WLED [1S4P] , W/O Driver |
| ontwerp vir | Mobile Phone |
| raakpaneel | Without |
