| Onderdeel nommer | TM028HDZ58 |
| Handelsmerk | TIANMA |
| Grootte | 2.8 |
| Toepassing | Mobile Phone |
| Resolusie | 240×320 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | 65K/262K |
| Agterlig | 1S4P |
| Koppelvlak | Parallel |
| vervaardiger | TIANMA |
| model naam | TM028HDZ58 |
| skerm grootte | 2.8 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 240(RGB)×320 (QVGA) 141PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 43.2 × 57.6 (H×V) |
| buitelyn (mm) | - |
| helderheid | - |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| kykhoek | 60/60/60/50 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | 6 o'clock |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 65K/262K 55% NTSC |
| agterlig | 1S4P WLED , No Driver |
| massa | - |
| gebruik vir | Mobile Phone |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | Parallel RGB (1 ch, 6-bit) + SPI |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
