| Onderdeel nommer | TM028HDHG30 |
| Handelsmerk | TIANMA |
| Grootte | 2.8 |
| Toepassing | Handheld & PDA |
| Resolusie | 240×320 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | TIANMA |
| paneel model | TM028HDHG30 |
| paneel grootte | 2.8" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 240(RGB)×320, QVGA, 141PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 43.2(W)×57.6(H) mm |
| ring opening | - |
| helderheid | - |
| kontras verhouding | 500:1 (Typ.) (TM) |
| kykhoek | - |
| vertoonmodus | TN, Normally White, Transmissive |
| beste uitsig op | - |
| reaksie tyd | 20 (Typ.)(Tr+Td) |
| kleure vertoon | 262K 65% NTSC |
| tipe lamp | WLED |
| frekwensie | - |
| raakskerm | Without |
| paneel gewig | - |
| aansoek | Handheld & PDA |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| 28QVF2H | SII | 2.8 | 240×320 |
| BTL282440-310L | BOE | 2.8 | 240×400 |
| ET028002DMU | EDT | 2.8 | 240×320 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| PJ028MA-01A | Innolux | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
