| Onderdeel nommer | TM026HDH02 |
| Handelsmerk | TIANMA |
| Grootte | 2.6 |
| Toepassing | Mobile Phone |
| Resolusie | 240×320 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | 65K/262K |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | TIANMA |
| model naam | TM026HDH02 |
| skerm grootte | 2.6 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 240(RGB)×320 (QVGA) 156PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 38.88 × 51.84 (H×V) |
| buitelyn (mm) | - |
| helderheid | 240 cd/m² (Typ.) |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| kykhoek | 70/70/70/60 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | 6 o'clock |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 65K/262K 60% NTSC |
| agterlig | WLED , No Driver |
| massa | TBD |
| gebruik vir | Mobile Phone |
| herlaaitempo | - |
| raakskerm | Without |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 60 °C |
| A026EAN01.0 | AUO | 2.6 | 800×1280 |
| AMDM001 | Samsung | 2.6 | 240×400 |
| AMS260CM61 | Samsung | 2.6 | 240×320 |
| L5F30774P01 | Epson | 2.6 | 240×320 |
| LS026B8PX04 | SHARP | 2.6 | 240×400 |
| LS026Q3DX01 | SHARP | 2.6 | 240×320 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| TD026TTEA1 | TPO | 2.6 | 480×640 |
