| Onderdeel nommer | TL139GDXP01-00 |
| Handelsmerk | TIANMA |
| Grootte | 13.9 |
| Toepassing | Laptop |
| Resolusie | 3000×2000 |
| Samestelling | LTPS TFT-LCD, LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | TIANMA |
| paneel model | TL139GDXP01-00 |
| paneel grootte | 13.9" |
| paneel tipe | LTPS TFT-LCD, LCM |
| resolusie | 3000(RGB)×2000, 259PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 293.85(W)×195.9(H) mm |
| ring opening | - |
| helderheid | 420 cd/m² (Typ.) |
| kontras verhouding | 1500:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | SFT, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | - |
| kleure vertoon | 16.7M 72% NTSC |
| tipe lamp | WLED |
| frekwensie | 60Hz |
| raakskerm | - |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| aansoek | Laptop |
| sein koppelvlak | eDP |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
