| Onderdeel nommer | TL055BDXP03 |
| Handelsmerk | TIANMA |
| Grootte | 5.5 |
| Toepassing | Mobile Phone |
| Resolusie | 1440×2560 |
| Samestelling | LCM , LTPS TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | 5S3P |
| Koppelvlak | MIPI |
| vervaardiger | TIANMA |
| skerm grootte | 5.5 inch |
| pixel nommer | 1440(RGB)×2560 (Quad-HD) 537PPI |
| aktiewe area (mm) | 68.04 × 120.96 (H×V) |
| helderheid | - |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 70% NTSC |
| massa | TBD |
| herlaaitempo | 70Hz |
| sein tipe | MIPI (2 ch, 4 data lanes) , 50 pins Connector |
| spanningstoevoer | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| maks. graderings | Storage Temp.: -30 ~ 70 °C Operating Temp.: -30 ~ 60 °C |
| model naam | TL055BDXP03 |
| tipe skerm | LCM , LTPS TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 70.94 × 128.29 × 1.46 (H×V×D) |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| reaksie | 8 (Typ.)(Tr+Td) ms |
| werksmodus | SFT, Normally Black, Transmissive |
| agterlig | 5S3P WLED |
| gebruik vir | Mobile Phone |
| raakskerm | Without |
| LH550WF1-SD01 | LG Display | 5.5 | 1080×1920 |
| LH550WF4-SD01 | LG Display | 5.5 | 1080×1920 |
| LQ055T3SX02 | SHARP | 5.5 | 1080×1920 |
| LQ055W1GC01 | SHARP | 5.5 | 1024×600 |
| LS055T1SX01 | SHARP | 5.5 | 1080×1920 |
| NL3224AC35-06 | NLT | 5.5 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| PJ055IA-14C | Innolux | 5.5 | 1080×1920 |
| UG-5664ASYGF01 | WiseChip | 5.5 | 256×64 |
