| Onderdeel nommer | TCG085WVLCF-G00 |
| Handelsmerk | Kyocera |
| Grootte | 8.5 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | Parallel |
| vervaardiger | Kyocera |
| model naam | TCG085WVLCF-G00 |
| skerm grootte | 8.5 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 800(RGB)×480 (WVGA) 109PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 184.8 × 110.88 (H×V) |
| buitelyn (mm) | 210 × 134 × 11.1 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare |
| helderheid | 320 cd/m² (Typ.) |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| kykhoek | 60/60/60/45 (Typ.)(CR≥10) |
| reaksie | 15/35 (Typ.)(Tr/Td) ms |
| goeie uitsig by | - |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 262K 49% NTSC |
| agterlig | WLED , 50K hours , No Driver |
| massa | TBD |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | 4-wire Resistive Touch, G/G |
| sein tipe | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| G085VW01 V0 | AUO | 8.5 | 800×480 |
| G085VW01 V1 | AUO | 8.5 | 800×480 |
| G085VW01 V3 | AUO | 8.5 | 800×480 |
| KMT085WV | Samsung | 8.5 | 800×480 |
| LM085YB1T01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG18 | SHARP | 8.5 | 800×480 |
| LT085AC18N00 | TOSHIBA | 8.5 | 800×480 |
| LW850AT9301 | Innolux | 8.5 | 800×480 |
