| Onderdeel nommer | TCG070WVLPAANN-AN50-S |
| Handelsmerk | Kyocera |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K |
| Agterlig | 2 |
| Koppelvlak | Parallel |
| paneel handelsmerk | Kyocera |
| paneel grootte | 7.0" |
| resolusie | 800(RGB)×480, WVGA, 133PPI |
| vertoon area | 152.4(W)×91.44(H) mm |
| omtrek grootte | 165(W)×104.4(H) ×8.5(D) mm |
| helderheid | 900 cd/m² (Typ.) |
| kykhoek | 80/80/60/80 (Typ.)(CR≥10) |
| beste uitsig op | 12 o'clock |
| kleure vertoon | 262K 49% NTSC |
| frekwensie | - |
| paneel gewig | 195g (Typ.) |
| sein koppelvlak | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| paneel model | TCG070WVLPAANN-AN50-S |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 154.4(W)×93.4(H) mm |
| oppervlak | Antiglare |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 5/25 (Typ.)(Tr/Td) |
| tipe lamp | 2 strings WLED , 50K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial |
