| Onderdeel nommer | T645HW02 V5 |
| Handelsmerk | AUO |
| Grootte | 65 |
| Toepassing | LCTV |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 450 |
| CR | 4000:1 |
| Kleure | 1.07B |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | AUO |
| paneel model | T645HW02 V5 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 65 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | AMVA3, Normally Black, Transmissive |
| aktiewe area | 1428.48×803.52 mm |
| buitelyn | 1508×878 mm |
| oppervlak | Antiglare (Haze 2%), Hard coating (3H) |
| helderheid | 450 cd/m² (Typ.) |
| kontras verhouding | 4000:1 (Typ.) |
| kleure vertoon | 1.07B (8-bit + Hi-FRC), CIE193172% |
| reaksie tyd | 5.5 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 120Hz |
| tipe lamp | CCFLEmbedded (Inverter) |
| sein koppelvlak | LVDS (4 ch, 10-bit), 92 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | LCTV |
| HV650QUB-B00 | BOE | 65 | 3840×2160 |
| LC650EQF-FJM1 | LG Display | 65 | 3840×2160 |
| P645HW01 V0 | AUO | 65 | 1920×1080 |
| T645HB01 V0 | AUO | 65 | 1920×1080 |
| T645HF02 V1 | AUO | 65 | 1920×1080 |
| T645HW02 V3 | AUO | 65 | 1920×1080 |
| T645HW02 V5 | AUO | 65 | 1920×1080 |
| T645HW04 V0 CELL | AUO | 65 | 1920×1080 |
| T645HW05 V0 | AUO | 65 | 1920×1080 |
| T650HVN07.0 | AUO | 65 | 1920×1080 |
| HV480FH2-600 | BOE | 48 | 1920×1080 |
| LC370WUG-SCA2 | LG Display | 37 | 1920×1080 |
| LC420DUE-SFR2 | LG Display | 42 | 1920×1080 |
| LC470DUE-FGA3 | LG Display | 47 | 1920×1080 |
| LC650DUF-FGF1 | LG Display | 65 | 1920×1080 |
| LSC460HN05-W | Samsung | 46 | 1920×1080 |
| LTA460HB03 | Samsung | 46 | 1920×1080 |
| V260B1-L11 | Innolux | 26.0 | 1366×768 |
| V315H3-L01 | Innolux | 31.5 | 1920×1080 |
| V580HJ1-PD6 | Innolux | 58 | 1920×1080 |
