T320XW04 V3 CELL

T320XW04 V3 CELL
T320XW04 V3 CELL thumb
Handelsmerk
AUO
Grootte
31.5
Toepassing
LCTV
Resolusie
1366×768
Samestelling
CELL
Helderheid
0
CR
3000:1
Kleure
16.7M
Agterlig
No B/L
Koppelvlak
LVDS
In Stock
1
Spesifikasies

Onderdeel nommer T320XW04 V3 CELL
HandelsmerkAUO
Grootte31.5
ToepassingLCTV
Resolusie1366×768
SamestellingCELL
Helderheid0
CR3000:1
Kleure16.7M
AgterligNo B/L
KoppelvlakLVDS
paneel handelsmerkAUO
paneel modelT320XW04 V3 CELL
paneel tipe a-Si TFT-LCD , CELL
paneel grootte31.5 inch
resolusie1366(RGB)×768 , WXGA
vertoonmodusMVA, Normally Black, Transmissive
aktiewe area697.685×392.256 mm
buitelyn716.1×408.7 mm
oppervlakAntiglare (Haze 2%), Hard coating (3H)
kontras verhouding3000:1 (Typ.)
kleure vertoon16.7M (8-bit), CIE193172%
reaksie tyd6.5 (Typ.)(G to G)
kykhoek89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekwensie60Hz
sein koppelvlakLVDS (1 ch, 8-bit), 30 pins
insetspanning12.0V (Typ.)
aansoekLCTV
