T315XW06 V5

T315XW06 V5
T315XW06 V5
T315XW06 V5
T315XW06 V5 thumb T315XW06 V5 thumb T315XW06 V5 thumb
Handelsmerk
AUO
Grootte
31.5
Toepassing
LCTV
Resolusie
1366×768
Samestelling
LCM
Helderheid
350
CR
3000:1
Kleure
16.7M
Agterlig
WLED
Koppelvlak
LVDS
In Stock
12676
Spesifikasies

Onderdeel nommer T315XW06 V5
HandelsmerkAUO
Grootte31.5
ToepassingLCTV
Resolusie1366×768
SamestellingLCM
Helderheid350
CR3000:1
Kleure16.7M
AgterligWLED
KoppelvlakLVDS
paneel handelsmerkAUO
paneel modelT315XW06 V5
paneel tipe a-Si TFT-LCD , LCM
paneel grootte31.5 inch
resolusie1366(RGB)×768 , WXGA
vertoonmodusAMVA, Normally Black, Transmissive
aktiewe area697.685×392.256 mm
buitelyn735.4×433 mm
oppervlakAntiglare (Haze 2%), Hard coating (3H)
helderheid350 cd/m² (Typ.)
kontras verhouding3000:1 (Typ.)
kleure vertoon16.7M (8-bit), CIE193172%
reaksie tyd6.5 (Typ.)(G to G)
kykhoek89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekwensie60Hz
tipe lampWLEDEmbedded (LED Driver)
sein koppelvlakLVDS (1 ch, 8-bit), 30 pins
insetspanning12.0V (Typ.)
aansoekLCTV
Familie Model
T315XW01 V9 AUO 31.5 1366×768
T315XW02 VK AUO 31.5 1366×768
T315XW02 VL AUO 31.5 1366×768
T315XW03 VD AUO 31.5 1366×768
T315XW03 VE AUO 31.5 1366×768
T315XW04 V3 AUO 31.5 1366×768
T315XW06 V3 AUO 31.5 1366×768
T315XW06 V5 AUO 31.5 1366×768
T315XW07 V0 AUO 31.5 1366×768
T315XW07 V2 AUO 31.5 1366×768
