| Onderdeel nommer | T215HVN05.0 CELL |
| Handelsmerk | AUO |
| Grootte | 21.5 |
| Toepassing | Desktop Monitor TV S |
| Resolusie | 1920×1080 |
| Samestelling | CELL , a-Si TFT-LC |
| Helderheid | |
| CR | 3000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| vervaardiger | AUO |
| skerm grootte | 21.5 inch |
| pixel nommer | 1920(RGB)×1080 (FHD) 102PPI |
| aktiewe area (mm) | 476.064 × 267.786 (H×V) |
| ring area (mm) | - |
| helderheid | 0 cd/m² |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| glas dikte | 0.50+0.50 mm |
| kleurdiepte | 16.7M 76% NTSC |
| massa | 415g (Typ.) |
| herlaaitempo | 60Hz |
| bestuurder ic lys | Built-in COF 6 source chips |
| sein tipe | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model naam | T215HVN05.0 CELL |
| tipe skerm | CELL , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 483.864 × 278.386 × 1.41 (H×V×D) |
| behandeling | Antiglare, Hard coating (3H) |
| kontras verhouding | 3000 : 1 (Typ.) (TM) |
| reaksie | 13/5 (Typ.)(Tr/Td); 28 (Typ.)(G to G) ms |
| werksmodus | VA, Normally Black, Transmissive |
| deurlaatbaarheid | 3.6% (Typ.)(with Polarizer) |
| agterlig | No B/L |
| gebruik vir | Desktop Monitor TV Sets |
| raakskerm | Without |
| LC215EUE-SDP1 | LG Display | 21.5 | 1920×1080 |
| LM215DB-T02 | PANDA | 21.5 | 1920×1080 |
| LM215DT8A | PANDA | 21.5 | 1920×1080 |
| LM215WF2-SLC1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLC1 | LG Display | 21.5 | 1920×1080 |
| LM215WF5-SLA1 | LG Display | 21.5 | 1920×1080 |
| LTM215HT03 | Samsung | 21.5 | 1920×1080 |
| M215HGE-L10 | Innolux | 21.5 | 1920×1080 |
| T215HVN01.0 | AUO | 21.5 | 1920×1080 |
| T215HVN01.1 | AUO | 21.5 | 1920×1080 |
