| Onderdeel nommer | STCG057QVLAD-G00 |
| Handelsmerk | Kyocera |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 320×240 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | Parallel |
| vervaardiger | Kyocera |
| model naam | STCG057QVLAD-G00 |
| skerm grootte | 5.7 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 320(RGB)×240 (QVGA) 70PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 115.2 × 86.4 (H×V) |
| buitelyn (mm) | - |
| ring area (mm) | - |
| behandeling | Glare (Haze 0%) |
| helderheid | - |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥5) |
| reaksie | 10/25 (Typ.)(Tr/Td) ms |
| goeie uitsig by | - |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 262K |
| agterlig | WLED |
| massa | - |
| gebruik vir | Industrial |
| herlaaitempo | - |
| raakskerm | 4-wire Resistive Touch |
| sein tipe | Parallel RGB (1 ch, 6-bit) |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
