| Onderdeel nommer | ST7461D02-5 |
| Handelsmerk | CSOT |
| Grootte | 75 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 6000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | USI-T |
| paneel handelsmerk | CSOT |
| paneel model | ST7461D02-5 |
| paneel grootte | 75" |
| paneel tipe | a-Si TFT-LCD, CELL |
| resolusie | 3840(RGB)×2160, UHD, 59PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 1650.24(W)×928.26(H) mm |
| ring opening | - |
| omtrek grootte | 1662.24(W)×941.96(H) ×1.34(D) mm |
| oppervlak | Antiglare (Haze 2%), Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 6000:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | HVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 6.5 (Typ.)(G to G) |
| glas diepte | 0.50+0.50 mm |
| deurlaatbaarheid | 5.5% (Typ.)(with Polarizer) |
| kleure vertoon | 1.07B 93% DCI-P3 |
| tipe lamp | No B/L |
| frekwensie | 120Hz |
| raakskerm | Without |
| bestuurder ic | COFBuilt-in 12 source chips |
| paneel gewig | 4.77Kgs (Typ.) |
| aansoek | TV Sets |
| sein koppelvlak | USI-T , 192 pins Connector |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
