| Onderdeel nommer | ST5461B03-5 |
| Handelsmerk | CSOT |
| Grootte | 55 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 4000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| handelsmerk | CSOT |
| diagonale grootte | 55 inch |
| pixel formaat | 1920(RGB)×1080 [FHD] 40PPI |
| aktiewe area | 1209.6(H)×680.4(V) mm |
| ring area | - |
| helderheid | 0 cd/m² |
| kyk rigting | Symmetry |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| plaat dikte | 0.50+0.50 mm |
| ondersteun kleur | 16.7M 72% NTSC |
| gewig | 3.50Kgs (Max.) |
| raamkoers | 60Hz |
| d-ic detail | COF Built-in 6 source + 8 gate chips |
| koppelvlak tipe | LVDS (2 ch, 8-bit) , 51 pins Connector |
| kragtoevoer | 12.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | ST5461B03-5 |
| tipe | a-Si TFT-LCD , CELL |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 1223.6(H)×697.1(V) ×1.35(D) mm |
| behandeling | Antiglare (Haze 2%), Hard coating (3H) |
| kontras verhouding | 4000:1 (Typ.) (TM) |
| reaksie tyd | 7 (Typ.)(G to G) |
| bedryfsmodus | HVA, Normally Black, Transmissive |
| oordrag | 6.5% (Typ.)(with Polarizer) |
| Ligbron | No B/L |
| ontwerp vir | TV Sets |
| raakpaneel | Without |
