| Onderdeel nommer | SG2701B01-4 |
| Handelsmerk | CSOT |
| Grootte | 27.0 |
| Toepassing | Desktop Monitor |
| Resolusie | 1920×1080 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 4000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| vervaardiger | CSOT |
| model naam | SG2701B01-4 |
| skerm grootte | 27.0 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×1080 (FHD) 81PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 597.888 × 336.312 (H×V) |
| buitelyn (mm) | 608.888 × 348.337 × 1.24 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare (Haze 25%) |
| helderheid | 0 cd/m² |
| kontras verhouding | 4000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 8 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | HVA, Normally Black, Transmissive |
| glas dikte | 0.40+0.50 mm |
| deurlaatbaarheid | 4.6% (Typ.)(with Polarizer) |
| kleurdiepte | 16.7M 99% sRGB |
| agterlig | No B/L |
| massa | - |
| gebruik vir | Desktop Monitor |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| bestuurder ic lys | Built-in COF 6 source chips |
| sein tipe | LVDS (2 ch, 8-bit) , Connector 30 pins |
| spanningstoevoer | 12.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
