| Onderdeel nommer | SG2701B01-3 |
| Handelsmerk | CSOT |
| Grootte | 27.0 |
| Toepassing | Desktop Monitor Gami |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 4000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| handelsmerk | CSOT |
| model | SG2701B01-3 |
| diagonale grootte | 27.0 inch |
| tipe | a-Si TFT-LCD, CELL |
| pixel formaat | 1920(RGB)×1080 [FHD] 81PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 597.888(H)×336.312(V) mm |
| buitelyn dof. | 608.888(H)×348.337(V) ×1.3(D) mm |
| ring area | - |
| behandeling | Antiglare (Haze 25%) |
| helderheid | 0 cd/m² |
| kontras verhouding | 4000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 12 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | HVA, Normally Black, Transmissive |
| plaat dikte | 0.40+0.50 mm |
| oordrag | 4.6% (Typ.)(with Polarizer) |
| ondersteun kleur | 16.7M 99% sRGB |
| Ligbron | No B/L |
| gewig | - |
| ontwerp vir | Desktop Monitor Gaming |
| raamkoers | 165Hz |
| raakpaneel | Without |
| d-ic detail | COF Built-in 6 source chips |
| koppelvlak tipe | LVDS (4 ch, 8-bit) , 61 pins Connector |
| kragtoevoer | 12.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
