| Onderdeel nommer | RV059FBB-N80 |
| Handelsmerk | BOE |
| Grootte | 5.9 |
| Toepassing | 3D Printer |
| Resolusie | 1620×2560 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1100:1 |
| Kleure | Monochrome |
| Agterlig | No |
| Koppelvlak | |
| handelsmerk | BOE |
| model | RV059FBB-N80 |
| diagonale grootte | 5.9 inch |
| tipe | a-Si TFT-LCD, CELL |
| pixel formaat | 1620×2560 508PPI |
| konfigurasie | Rectangle |
| aktiewe area | 81(H)×128(V) mm |
| buitelyn dof. | 84.6(H)×135.85(V) ×0.95(D) mm |
| helderheid | 0 cd/m² |
| kontras verhouding | 1100:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 35 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Min.)(CR≥10) |
| bedryfsmodus | ADS, Normally Black, Transmissive |
| plaat dikte | - |
| oordrag | 5.38% (Typ.) |
| ondersteun kleur | Monochrome |
| Ligbron | No B/L |
| gewig | - |
| ontwerp vir | 3D Printer |
| raamkoers | - |
| raakpaneel | Without |
| d-ic detail | COG Built-in 1 source chips |
| omgewing | Operating Temperature: 0 ~ 70 °C ; Storage Temperature: -10 ~ 80 °C |
