| Onderdeel nommer | QV101WUB-N80 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1920×1200 |
| Samestelling | CELL , a-Si TFT-LC |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | |
| vervaardiger | BOE |
| skerm grootte | 10.1 inch |
| pixel nommer | 1920(RGB)×1200 (WUXGA) 224PPI |
| aktiewe area (mm) | 216.806 × 135.504 (H×V) |
| ring area (mm) | - |
| helderheid | 0 (cd/m²) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| glas dikte | - |
| kleurdiepte | 16.7M 72% NTSC |
| massa | - |
| herlaaitempo | 60Hz |
| model naam | QV101WUB-N80 |
| tipe skerm | CELL , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 221.81 × 145.5 (H×V×D) |
| behandeling | Hard coating |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| werksmodus | ADS, Normally Black, Transmissive |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| deurlaatbaarheid | 3.85% (Typ.)(with Polarizer) |
| agterlig | No B/L |
| gebruik vir | Industrial |
| raakskerm | Without |
