| Onderdeel nommer | PV190E0M-N10 |
| Handelsmerk | BOE |
| Grootte | 19.0 |
| Toepassing | Industrial |
| Resolusie | 1280×1024 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | BOE |
| skerm grootte | 19.0 inch |
| pixel nommer | 1280(RGB)×1024 (SXGA) 86PPI |
| aktiewe area (mm) | 374.784 × 299.827 (H×V) |
| ring area (mm) | 379 × 303 (H×V) |
| helderheid | 400 (Typ.)(cd/m²) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 73% NTSC |
| massa | 1.95Kgs (Typ.) |
| herlaaitempo | 60Hz |
| model naam | PV190E0M-N10 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 396 × 324 × 12.13 (H×V×D) |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| werksmodus | ADS, Normally Black, Transmissive |
| reaksie | 14 (Typ.)(G to G) ms |
| agterlig | WLED , 50K hours , No Driver |
| gebruik vir | Industrial |
| raakskerm | Without |
| G190ETN01.1 | AUO | 19.0 | 1280×1024 |
| LM190E08-TLGD | LG Display | 19.0 | 1280×1024 |
| LTM190BT03 | Samsung | 19.0 | 1440×900 |
| M190A1-L07 | Innolux | 19.0 | 1440×900 |
| M190EN01 V1 | AUO | 19.0 | 1280×1024 |
| M190EN04 V5 | AUO | 19.0 | 1280×1024 |
| M190PW01 V0 | AUO | 19.0 | 1440×900 |
| M190PW01 V8 | AUO | 19.0 | 1440×900 |
| MT190AW02 V.A | Innolux | 19.0 | 1440×900 |
| MT190EN02 V.W | Innolux | 19.0 | 1280×1024 |
