| Onderdeel nommer | PT156WHM-N10 |
| Handelsmerk | BOE |
| Grootte | 15.6 |
| Toepassing | Industrial |
| Resolusie | 1366×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | 10S4P |
| Koppelvlak | |
| paneel handelsmerk | BOE |
| paneel grootte | 15.6" |
| resolusie | 1366(RGB)×768, WXGA, 100PPI |
| vertoon area | 344.23(W)×193.54(H) mm |
| omtrek grootte | 359.5(W)×223.8(H) ×3.2(D) mm |
| helderheid | 400 cd/m² (Typ.) |
| kykhoek | 45/45/20/40 (Typ.)(CR≥10) |
| beste uitsig op | - |
| kleure vertoon | 262K 45% NTSC |
| frekwensie | 60Hz |
| gewig | 370g (Max.) |
| paneel model | PT156WHM-N10 (BOE06A5) |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 12 (Typ.)(Tr+Td) |
| tipe lamp | 10S4P WLED , 30K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial |
