| Onderdeel nommer | P270DAN01.0 |
| Handelsmerk | AUO |
| Grootte | 27.0 |
| Toepassing | Digital Signage |
| Resolusie | 2560×1440 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 1.07B |
| Agterlig | GB-LED |
| Koppelvlak | LVDS |
| vervaardiger | AUO |
| skerm grootte | 27.0 inch |
| pixel nommer | 2560(RGB)×1440 (Quad-HD) 108PPI |
| aktiewe area (mm) | 596.736 × 335.664 (H×V) |
| ring area (mm) | 601.6 × 340.15 (H×V) |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 1.07B 99% Adobe RGB |
| massa | - |
| herlaaitempo | 60Hz |
| sein tipe | LVDS (4 ch, 10-bit) , 92 pins Connector |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model naam | P270DAN01.0 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 630 × 371.8 (H×V×D) |
| behandeling | Antiglare, Hard coating (3H) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| reaksie | 12 (Typ.)(G to G) ms |
| werksmodus | AHVA, Normally Black, Transmissive |
| agterlig | GB-LED , 30K hours , No Driver |
| gebruik vir | Digital Signage |
| raakskerm | Without |
