| Onderdeel nommer | P101DEA-AZ0 |
| Handelsmerk | Innolux |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 800×1280 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 4 |
| Koppelvlak | MIPI |
| vervaardiger | Innolux |
| model naam | P101DEA-AZ0 |
| skerm grootte | 10.1 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 800(RGB)×1280 (WXGA) 150PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 135.36 × 216.576 (H×V) |
| buitelyn (mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| ring area (mm) | - |
| behandeling | Glare (Haze 0%), Hard coating |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Min.)(CR≥10) |
| reaksie | 35 (Max.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AAS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 60% NTSC |
| agterlig | 4 strings WLED , 15K hours , No Driver |
| massa | 175g (Max.) |
| gebruik vir | Pad & Tablet |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | MIPI (4 data lanes) , Connector 40 pins |
| spanningstoevoer | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| maks. graderings | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
