| Onderdeel nommer | P0650VGF1MA10 |
| Handelsmerk | TIANMA |
| Grootte | 6.5 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 640×480 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 900:1 |
| Kleure | 262K/16.7M |
| Agterlig | 6S2P |
| Koppelvlak | LVDS |
| paneel handelsmerk | TIANMA |
| paneel model | P0650VGF1MA10 |
| paneel grootte | 6.5" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 640(RGB)×480, VGA, 122PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 132.48(W)×99.36(H) mm |
| ring opening | 135.48(W)×102.36(H) mm |
| omtrek grootte | 153(W)×118(H) ×11.2(D) mm |
| oppervlak | Antiglare |
| helderheid | 800 cd/m² (Typ.) |
| kontras verhouding | 900:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | SFT, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kleure vertoon | 262K/16.7M 70% NTSC |
| tipe lamp | 6S2P WLED , 70K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | TBD |
| aansoek | Industrial Outdoor High Brightness Automotive Display |
| sein koppelvlak | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.0G (19.6 m/s²) |
