| Onderdeel nommer | NV101WUM-N53 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | BOE |
| model | NV101WUM-N53 |
| diagonale grootte | 10.1 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1200(RGB)×1920 [WUXGA] 225PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 135.36(H)×216.576(V) mm |
| buitelyn dof. | 141.6(H)×227.406(V) mm |
| ring area | - |
| behandeling | Anti Fingerprint + Clear, Hard coating |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | HADS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 74% NTSC |
| Ligbron | WLED [8S4P] , 15K hours , W/O Driver |
| gewig | 105g (Typ.) |
| ontwerp vir | Pad & Tablet |
| raamkoers | 60Hz |
| raakpaneel | Without |
| Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
