| Onderdeel nommer | NT133WHM-N23 |
| Handelsmerk | BOE |
| Grootte | 13.3 |
| Toepassing | Laptop |
| Resolusie | 1366×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | 9S4P |
| Koppelvlak | eDP |
| paneel handelsmerk | BOE |
| paneel grootte | 13.3" |
| resolusie | 1366(RGB)×768, WXGA, 118PPI |
| vertoon area | 293.42(W)×164.97(H) mm |
| omtrek grootte | 306.3(W)×188.75(H) ×3.6(D) mm |
| helderheid | 220 cd/m² (Typ.) |
| kykhoek | 45/45/20/40 (Typ.)(CR≥10) |
| beste uitsig op | 6 o'clock |
| kleure vertoon | 262K 48% NTSC |
| frekwensie | 60Hz |
| vorm styl | Flat (PCBA Flat, T3.4~4.0mm) |
| sein koppelvlak | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| paneel model | NT133WHM-N23 (BOE06D8) |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 12 (Typ.)(Tr+Td) |
| tipe lamp | 9S4P WLED , 15K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Laptop |
