| Onderdeel nommer | NT116WHM-A20 |
| Handelsmerk | BOE |
| Grootte | 11.6 |
| Toepassing | Laptop |
| Resolusie | 1366×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | 8S4P |
| Koppelvlak | |
| paneel handelsmerk | BOE |
| paneel grootte | 11.6" |
| resolusie | 1366(RGB)×768, WXGA, 135PPI |
| vertoon area | 256.125(W)×144(H) mm |
| omtrek grootte | 278(W)×171.55(H) ×4.9(D) mm |
| helderheid | 200 cd/m² (Typ.) |
| kykhoek | 45/45/20/40 (Typ.)(CR≥10) |
| beste uitsig op | 6 o'clock |
| kleure vertoon | 262K 48% NTSC |
| frekwensie | 60Hz |
| vorm styl | Flat (PCBA Flat, T3.4~4.0mm) |
| paneel model | NT116WHM-A20 (BOE063F) |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Hard coating (7H) |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 12 (Typ.)(Tr+Td) |
| tipe lamp | 8S4P WLED , 15K hours , With LED Driver |
| raakskerm | PCAP, Optical Bonding |
| aansoek | Laptop |
