| Onderdeel nommer | NL6448BC33-50 |
| Handelsmerk | NLT |
| Grootte | 10.4 |
| Toepassing | IA |
| Resolusie | 640×480 |
| Samestelling | LCM |
| Helderheid | 250 |
| CR | 100:1 |
| Kleure | 262K |
| Agterlig | CCFL |
| Koppelvlak | TTL |
| paneel handelsmerk | NEC |
| paneel model | NL6448BC33-50 1 Compatible model |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 10.4 inch |
| resolusie | 640(RGB)×480 , VGA |
| vertoonmodus | TN, Normally White, Transflective |
| aktiewe area | 211.2×158.4 mm |
| buitelyn | 243×185.1×11.5 mm |
| oppervlak | Clear, Hard coating (2H), Antireflection |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| kleure vertoon | 262K (6-bit), CIE193150% |
| reaksie tyd | 5/20 (Typ.)(Tr/Td) |
| kykhoek | 75/55/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 2 pcsCCFLWithout Driver |
| sein koppelvlak | CMOS (1 ch, 6-bit), 31 pins |
| insetspanning | 3.3/5.0V (Typ.)(VCC) |
| aansoek | IA |
