| Onderdeel nommer | NL256204AM15-02A |
| Handelsmerk | NLT |
| Grootte | 20.1 |
| Toepassing | DMPC |
| Resolusie | 2560×2048 |
| Samestelling | LCM |
| Helderheid | 850 |
| CR | 600:1 |
| Kleure | Grayscale |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | NEC |
| paneel model | NL256204AM15-02A |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 20.1 inch |
| resolusie | 2560(LCR)×2048 , QSXGA |
| vertoonmodus | SA-SFT, Normally Black, Transmissive |
| aktiewe area | 399.36×319.49 mm |
| buitelyn | 423.4×343.5×45.5 mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 850 cd/m² (Typ.) |
| kontras verhouding | 600:1 (Typ.) |
| kleure vertoon | Grayscale (8-bit) |
| reaksie tyd | 15/15 (Typ.)(Tr/Td) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 12 pcsCCFLEmbedded (Inverter) |
| sein koppelvlak | LVDS (4 ch, 8-bit) |
| insetspanning | 12.0V (Typ.) |
| rohs: | |
| aansoek | DMPC |
