| Onderdeel nommer | NL192120AC25-02 |
| Handelsmerk | NLT |
| Grootte | 22.5 |
| Toepassing | DMPC |
| Resolusie | 1920×1200 |
| Samestelling | LCM |
| Helderheid | 420 |
| CR | 800:1 |
| Kleure | 1.07B |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | NEC |
| paneel model | NL192120AC25-02 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 22.5 inch |
| resolusie | 1920(RGB)×1200 , WUXGA |
| vertoonmodus | UA-SFT, Normally Black, Transmissive |
| aktiewe area | 483.84×302.4 mm |
| buitelyn | 542×362 mm |
| oppervlak | Antiglare, Hard coating (2H) |
| helderheid | 420 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 1.07B (10-bit), Adobe97% |
| reaksie tyd | 6/6 (Typ.)(Tr/Td) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 120Hz |
| tipe lamp | 12 pcsCCFLEmbedded (Inverter) |
| sein koppelvlak | LVDS (4 ch, 10-bit), 104 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | DMPC |
