| Onderdeel nommer | NE156QUM-N64 |
| Handelsmerk | BOE |
| Grootte | 15.6 |
| Toepassing | Laptop |
| Resolusie | 3840×2160 |
| Samestelling | Oxide TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 10S6P |
| Koppelvlak | eDP |
| paneel handelsmerk | BOE |
| paneel grootte | 15.6" |
| resolusie | 3840(RGB)×2160, UHD, 283PPI |
| vertoon area | 344.218(W)×193.622(H) mm |
| omtrek grootte | 350.52(W)×205.92(H) ×4.6(D) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 72% NTSC |
| frekwensie | 60Hz |
| vorm styl | Slim (PCBA Bent, T≤3.0mm) |
| sein koppelvlak | eDP (4 Lanes) , eDP1.4a , HBR2 (5.4G/lane) , 40 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneel model | NE156QUM-N64 (BOE07D9) |
| paneel tipe | Oxide TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | ADS, Normally Black, Transmissive |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| tipe lamp | 10S6P WLED , 15K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Laptop |
