| Onderdeel nommer | NE140FHM-N46 |
| Handelsmerk | BOE |
| Grootte | 14.0 |
| Toepassing | Laptop |
| Resolusie | 1920×1080 |
| Samestelling | Oxide TFT-LCD , LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleure | 16.7M |
| Agterlig | 10S6P |
| Koppelvlak | |
| paneel handelsmerk | BOE |
| paneel grootte | 14.0" |
| resolusie | 1920(RGB)×1080, FHD, 157PPI |
| vertoon area | 309.312(W)×173.988(H) mm |
| omtrek grootte | 315.81(W)×186.26(H) ×4.4(D) mm |
| helderheid | 400 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 100% sRGB |
| frekwensie | 60Hz |
| vorm styl | Slim (PCBA Bent, T≤3.0mm) |
| paneel model | NE140FHM-N46 (BOE091B) |
| paneel tipe | Oxide TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 1500:1 (Typ.) (TM) |
| vertoonmodus | ADS, Normally Black, Transmissive |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| tipe lamp | 10S6P WLED , 15K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Laptop |
| B140HAT02.0 | AUO | 14.0 | 1920×1080 |
| HB140WX1-300 | BOE | 14.0 | 1366×768 |
| LP140WH4-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLD1 | LG Display | 14.0 | 1366×768 |
| LTN140AT26-L01 | Samsung | 14.0 | 1366×768 |
| LTN140KT03 | Samsung | 14.0 | 1600×900 |
| N140B6-D11 | Innolux | 14.0 | 1366×768 |
| N140BGE-L21 | Innolux | 14.0 | 1366×768 |
| N140BGE-L31 | Innolux | 14.0 | 1366×768 |
| N140BGE-L41 | Innolux | 14.0 | 1366×768 |
