| Onderdeel nommer | NE135FBM-N41 |
| Handelsmerk | BOE |
| Grootte | 13.5 |
| Toepassing | Laptop |
| Resolusie | 2256×1504 |
| Samestelling | Oxide TFT-LCD, LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleure | 16.7M |
| Agterlig | 9S6P |
| Koppelvlak | eDP |
| paneel handelsmerk | BOE |
| paneel model | NE135FBM-N41 (BOE08BC BOE095F) |
| paneel grootte | 13.5" |
| paneel tipe | Oxide TFT-LCD, LCM |
| resolusie | 2256(RGB)×1504, 201PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 284.933(W)×189.955(H) mm |
| ring opening | - |
| omtrek grootte | 289.993(W)×212.28(H) ×2.1(D) mm |
| oppervlak | Hard coating (2H) |
| helderheid | 415 cd/m² (Typ.) |
| kontras verhouding | 1500:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | FFS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kleure vertoon | 16.7M 100% sRGB |
| tipe lamp | 9S6P WLED , 15K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| aansoek | Laptop |
| sein koppelvlak | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 40 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
