| Onderdeel nommer | NE133QUM-N42 |
| Handelsmerk | BOE |
| Grootte | 13.3 |
| Toepassing | Laptop |
| Resolusie | 3840×2160 |
| Samestelling | LCM , Oxide TFT-LC |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 9S5P |
| Koppelvlak | eDP |
| vervaardiger | BOE |
| model naam | NE133QUM-N42 (BOE08CA) |
| skerm grootte | 13.3 inch |
| tipe skerm | LCM , Oxide TFT-LCD |
| pixel nommer | 3840(RGB)×2160 (UHD) 332PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 293.76 × 165.24 (H×V) |
| buitelyn (mm) | 298.76 × 176.42 × 4.6 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | ADS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 100% sRGB |
| agterlig | 9S5P WLED , 15K hours , With LED Driver |
| omtrek vorm | Slim (PCBA Bent, T≤3.0mm) |
| gebruik vir | Laptop |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
