| Onderdeel nommer | NE133QDM-N60 |
| Handelsmerk | BOE |
| Grootte | 13.3 |
| Toepassing | Laptop |
| Resolusie | 2560×1600 |
| Samestelling | Oxide TFT-LCD, LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleure | 1.06B |
| Agterlig | WLED |
| Koppelvlak | eDP |
| handelsmerk | BOE |
| model | NE133QDM-N60 (BOE0958) |
| diagonale grootte | 13.3 inch |
| tipe | Oxide TFT-LCD, LCM |
| pixel formaat | 2560(RGB)×1600 [WQXGA] 227PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 286.08(H)×178.8(V) mm |
| buitelyn dof. | 291.08(H)×195.3(V) ×2.5(D) mm |
| ring area | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 1500:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | ADS, Normally Black, Transmissive |
| ondersteun kleur | 1.06B 100% sRGB |
| Ligbron | WLED [11S5P] , 15K hours , With LED Driver |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| ontwerp vir | Laptop |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | eDP (4 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 40 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
