| Onderdeel nommer | NE133FHM-N57 |
| Handelsmerk | BOE |
| Grootte | 13.3 |
| Toepassing | Laptop |
| Resolusie | 1920×1080 |
| Samestelling | Oxide TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 10S6P |
| Koppelvlak | eDP |
| paneel handelsmerk | BOE |
| paneel grootte | 13.3" |
| resolusie | 1920(RGB)×1080, FHD, 166PPI |
| vertoon area | 293.76(W)×165.24(H) mm |
| omtrek grootte | 298.76(W)×181.33(H) ×2.44(D) mm |
| helderheid | 400 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 100% DCI-P3 |
| frekwensie | 60Hz |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| sein koppelvlak | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 30 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 70 °C |
| paneel model | NE133FHM-N57 (BOE087A) |
| paneel tipe | Oxide TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | - |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | FFS, Normally Black, Transmissive |
| reaksie tyd | 25 (Typ.)(Tr+Td); 25 (Typ.)(G to G) |
| tipe lamp | 10S6P QLED , 15K hours , Without Driver |
| raakskerm | Without |
| aansoek | Laptop |
