| Onderdeel nommer | N650HN01 V1 |
| Handelsmerk | Darwin |
| Grootte | 65 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 4000:1 |
| Kleure | 1.07B |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | Darwin |
| paneel model | N650HN01 V1 |
| paneel grootte | 65" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1920(RGB)×1080, FHD, 34PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 1428.48(W)×803.52(H) mm |
| ring opening | - |
| omtrek grootte | 1454.3(W)×831.5(H) ×31.6(D) mm |
| oppervlak | Antiglare (Haze 2%), Hard coating (3H), Antireflection |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 4000:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | AMVA3, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 8 (Typ.)(G to G) |
| kleure vertoon | 1.07B 72% NTSC |
| tipe lamp | WLED , 30K hours , With LED Driver |
| frekwensie | 120Hz |
| raakskerm | Without |
| paneel gewig | 25.5Kgs (Typ.) |
| aansoek | TV Sets |
| sein koppelvlak | LVDS (4 ch, 10-bit) , 92 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LC650EQF-FGF1 | LG Display | 65 | 3840×2160 |
| LC650EQK-FGK5 | LG Display | 65 | 3840×2160 |
| P650HVN05.0 | AUO | 65 | 1920×1080 |
| RX650-Z20 | ROGIN | 65 | 1920×1080 |
| T650HVD01.0 | AUO | 65 | 1920×1080 |
| T650HVF03.0 | AUO | 65 | 1920×1080 |
| T650HVN06.0 | AUO | 65 | 1920×1080 |
| V650DJ4-KS5 | Innolux | 65 | 3840×2160 |
| V650HP1-LS6 Rev.E | Innolux | 65 | 1920×1080 |
| V650HP1-ME2 | Innolux | 65 | 1920×1080 |
